What Effects Might Heat Not Burn Have?

As Heat not Burn products become more popular they’re steadily generating debate among the public, health activists and scientists. So far, the medical profession want to know how much safer they are than traditional tobacco products. Activists want to know if they’re part of a cunning plot to create more smokers. Smokers want to know how good they taste. This already seems like quite a lot to discuss – but it turns out some people are already thinking a lot further.

A few days ago Heat Not Burn UK had the opportunity to interview David O’Reilly, the director of science, research and development at British American Tobacco. David is a real expert on HnB and I had a fascinating discussion with him (so expect to see his name a few  times on this blog over the next month or so), and he’s been thinking way ahead of just about everyone else I’ve spoken to.

This Is The Future

One thing David was very clear on is that BAT, like Philip Morris, see non-combustible products as the future. While I was talking to him I noticed that he mentioned, more than once, moving to HnB. Eventually I asked him if he saw it as expanding their product range or repositioning it. “Our customers are moving to safer products,” he said. “We can move with them, or go out of business.” So BAT definitely seem committed to technological change.

What I hadn’t thought about was how far-reaching these changes could be. One of the products we talked about was Glo, BAT’s heated tobacco product. Glo uses “Neostiks”, similar to the Heets that feed PMI’s iQOS, and as you probably know there really isn’t a lot of tobacco in these. David explained just how inefficient a traditional cigarette is; about 90% of the tobacco in it ends up either in the filter or escaping as sidestream smoke; only about 10% of it is actually inhaled.

With a Glo this inefficiency just doesn’t exist. A Neostik has a filter but, like the one on a Heet, it’s mostly just there to give a familiar cigarette-like fee; it’s small and permeable enough that it traps very little of the vapour. Meanwhile there’s no sidestream problem either. In fact once a Glo is powered up and at working temperature it’s generating vapour constantly, but this stays in the heating chamber until you take a puff and inhale it – it doesn’t escape.

The end result is that a Neostik contains about 10% as much tobacco as a traditional cigarette, but it’s pretty much equivalent to it; if you smoke a pack of twenty every day, you’ll probably get through a pack of twenty Neostiks when you switch to Glo – but that’s as much tobacco as just two cigarettes.

Consequences?

I have to admit, I was sitting there making admiring noises about this efficiency when David said, “Of course, we have to think about what effect that will have on the tobacco farmers.”

Well, of course we do. After all, tens of thousands of people rely on tobacco farming for their livelihood. Many of them are in poor countries, too. A 90% fall in tobacco production could have a devastating effect on their economies. Tobacco controllers sometimes argue that tobacco takes up farmland that could be used for food, but the truth is the world isn’t short of food. When famines happen, which is a lot less often than they used to, it’s generally because there’s no way to get the food to the people who need it. Cutting tobacco production by 90% isn’t going to solve world hunger, but it could make a lot of people unemployed.

Then again it might not. The truth is, right now we simply don’t know. Will tobacco production fall significantly in the first place? We don’t know. A lot of it depends on what sort of reduced-risk products smokers actually move to. If they all switched to Glo then yes, a lot less tobacco would be needed. But so far the most popular alternatives are snus and e-cigarettes. Snus is made of tobacco, and e-cigs need nicotine – which is extracted from tobacco.

The most likely outcome is that there will continue to be a range of products, including snus, dissolvables and e-cigs as well as Heat not Burn devices. Total demand for tobacco will probably fall, but not dramatically at first. From the point of view of the farmers that’s likely to be good news. If demand changes gradually they can adjust and cope with it; it’s a sudden shock that would cause mass poverty.

What matters is that people are thinking about issues like this – and they are. Ironically it’s the tobacco industry, usually painted as the villain of the piece, who’s looking into the possible future effects of changing technology. Public health tend to just dismiss the fate of tobacco farmers, airily assuming that they can all start growing organic quinoa instead. Unfortunately life is rarely that simple.

Upping Their Game

The tobacco industry has a bad reputation, and leaked documents from the 1960s and 70s show that, a few decades ago at least, it was far from undeserved. They do also deserve some credit, though. BAT’s research facility in Southampton has been trying to develop a safer cigarette for decades; now they’ve abandoned that apparently hopeless quest and moved on to alternative products instead. They might have been late to the game on HnB and e-cigs, but they’re putting a lot of time and resources into it now.

In the last ten weeks I’ve spoken to researchers and senior executives from two of the world’s largest tobacco companies, and the impression I get is that they’re very serious about harm reduction. It’s unrealistic to expect them to stop selling cigarettes tomorrow, but they seem very determined to stop selling them at some point in the not too distant future. Another thing David O’Reilly, his colleagues from BAT and their opposite numbers at PMI all stressed to me is that products like Glo, iFuse and iQOS are early iterations of the technology. Some very clever people with very large research budgets are already working on improved versions that are simpler to use and give even better performance. The future for Heat not Burn, and every other category of reduced-risk tobacco product too, is looking very exciting.

iQOS Update – What’s Inside A Heet

One of the most popular pages on this site is our review of Philip Morris’s innovative iQOS device. That’s not much of a surprise, because iQOS has probably had more publicity than any other Heat not Burn product and it’s also the most widely available. It’s steadily rolling out beyond the first test markets and can now be bought in the UK, Spain, the Netherlands and several other countries; before too long it will be available globally, and I think it’s going to be a huge success.

When Heat not Burn UK first tested the iQOS the only sticks that came with it were mild menthols. Those were not as satisfying as they could have been, but did prove the concept. Happily, during our visit to PMI’s research centre at Neuchatel a couple of months ago there was no shortage of them in all flavours, and I got the chance to try an iQOS with a full-strength stick. I’m happy to report that it was very close to the experience of smoking a Marlboro, and an excellent substitute in every way.

Sticky Stuff

Obviously, what made the difference between “Meh, this is okay” on the first iQOS test and “Wow!” on the second one was the sticks it was being fed with. That means it’s probably time to look at the sticks themselves in a bit more detail.

The baby cigarettes that go in the end of an iQOS were originally called HeatSticks, but they’ve now been rebranded as “Heets from Marlboro”. Currently Heets come in three flavours – Amber, which roughly equates to full-strength Marlboro Red; Yellow, a lighter Marlboro Gold; and Turquoise, the mild menthol version. As far as I can tell these all have the same nicotine content, and the only difference is in the flavour.

Anyway, I just called them baby cigarettes. They’re not. Yes, they look like baby cigarettes, and they come in a tiny pack of twenty, but you can’t stick them in your mouth and fire them up with your trusty Zippo. That just won’t work. Even if it did work it would be pretty pointless, because the whole idea is that you don’t burn the tobacco.

In fact there really isn’t a lot of tobacco in there to burn, anyway. Looking at a Heet, you can see that the filter seems to take up about three-quarters of its length:

There are quite a few bits in here.

Not Just Tobacco

It’s not quite this simple, but we’ll come back to that. What’s in the other quarter is the stuff that gets heated, and I’ve actually had the chance to watch it being made in the factory at Neuchatel. PMI made me promise not to put all their trade secrets on the internet, but I can tell you the basics. What they do is blend selected tobaccos to get the flavour they want, then grind them to a fine powder. This is then mixed with water and some other ingredients – vegetable glycerine to keep it moist and generate the vapour; natural cellulose fibres to bind it; and guar (a natural gum) to hold the whole lot together.

This liquid mixture is sprayed onto a conveyor belt, run through a dryer then peeled off in thin sheets. The brown stuff in the end of a Heet is those sheets, rolled up like tobacco leaves in a cigar. When you load a Heet into your iQOS a steel blade in the device cuts into the roll, and when the blade heats up it creates the vapour for you to inhale. That vapour is mostly VG, loaded with aromatic flavours from the tobacco – which is why iQOS can replicate the flavour of a cigarette in a way that e-cigs can never quite manage.

So what else is in a Heet? Well, it’s not just the filter. In fact the filter itself is very short, as you can see:

From left to right: The tobacco, hollow tube, PLA and filter.

The actual filter is even smaller than the plug of tobacco at the other end, and it’s really only there to give you the familiar feel of a cigarette filter. Because iQOS doesn’t produce all the harsh combustion compounds you get from a cigarette there’s no real need for much filtration, so it can be very short. In fact if it was much longer it would probably soak up a lot of the VG vapour that you want to inhale.

After the filter is a loose roll of PLA, a very stable, food-safe plastic material. This is what does the real work; it slows the vapour down without absorbing it, giving it time to cool to a more pleasant temperature before you inhale it. This takes up almost half the length of the entire Heet.

Between the PLA and the tobacco is a short length of hollow tube, made of a similar material to the filter. As far as I understand it this is mainly to keep the blade away from the PLA and give the vapour a clear path to start its journey through the Heet. Then finally, at the end, you’ll find that little plug of tobacco.

Small But Complicated

So a Heet might look like a cigarette, but inside it’s a bit more complicated. This, and the fact they’re so small, means they’re also trickier to make; PMI had to do some creative rebuilding of some old but reliable cigarette-making machines to come up with something that would make Heets.

All this effort has paid off, though. It might be tiny, but a Heet will give as many puffs as a full-size cigarette. If you get the strength that suits you those puffs are just as satisfying, too. I had a few lingering doubts about iQOS after my first experiment with it in Poland last year, but using an identical device with Amber Heets was a totally different experience.

What’s most exciting is that, while iQOS isn’t the first generation of this technology, it’s still at a relatively early stage; there’s a lot of potential for development in there. I’m increasingly sure that HnB products like this have a very bright future in front of them.
